DATA SHEET · APCO-HYBRID-PARAMOTOR

APCO Hybrid Paramotor

The paramotor version of the Hybrid — the EN-B certified lightweight wing, factory-fitted with sheathed lines and paramotor risers. For pilots who want one wing for powered AND free flight.

DGAC/EN B 4 Sizes
Datasheet

APCO Hybrid Paramotor at a glance

Certification
EN-B / DGAC
Sizes
S · M · L · XL
All-up weight
70–140 kg
Area
20,00–25,56 m²
Cells
48–50
Canopy weight
3,0–3,3 kg
Speed
35–45 km/h
Min. sink
1,1 m/s
Colours
Blue · Greybird · Orange
Manual
Open PDF

Manufacturer data · Source

II · Highlights

Three reasons for APCO Hybrid Paramotor.

III · Sizes

Size chart.

Specifications per size for APCO Hybrid Paramotor (4 sizes).
Datasheet SMLXL
Cells 48484850
Area [m²] 20222425.56
Area (projected) [m²] 16.918.620.321.65
Span (incl. stabiliser) [m] 10.110.611.011.59
Span (projected) [m] 7.98.38.69.06
Aspect ratio 5.15.15.15.25
Aspect ratio (projected) 3.73.73.73.79
Max. chord [m] 2.432.542.652.65
Line length at B [m] 6.066.356.647.10
Total line length [m] 315324333352
Canopy weight [kg] 3.03.13.23.3
Certified weight range, powered [kg] 70-9585-110100-125115-140
V-min [km/h] 22222222
V-trim [km/h] 35353535
V-max [km/h] 45+45+45+45+
Min. sink at optimal wing loading [m/s] 1.11.11.11.1
Certification DGAC EN-BDGAC EN-BDGAC EN-BDGAC EN-B (EN-B*)
Size

S

Cells
48
Area [m²]
20
Area (projected) [m²]
16.9
Span (incl. stabiliser) [m]
10.1
Span (projected) [m]
7.9
Aspect ratio
5.1
Aspect ratio (projected)
3.7
Max. chord [m]
2.43
Line length at B [m]
6.06
Total line length [m]
315
Canopy weight [kg]
3.0
Certified weight range, powered [kg]
70-95
V-min [km/h]
22
V-trim [km/h]
35
V-max [km/h]
45+
Min. sink at optimal wing loading [m/s]
1.1
Certification
DGAC EN-B
Size

M

Cells
48
Area [m²]
22
Area (projected) [m²]
18.6
Span (incl. stabiliser) [m]
10.6
Span (projected) [m]
8.3
Aspect ratio
5.1
Aspect ratio (projected)
3.7
Max. chord [m]
2.54
Line length at B [m]
6.35
Total line length [m]
324
Canopy weight [kg]
3.1
Certified weight range, powered [kg]
85-110
V-min [km/h]
22
V-trim [km/h]
35
V-max [km/h]
45+
Min. sink at optimal wing loading [m/s]
1.1
Certification
DGAC EN-B
Size

L

Cells
48
Area [m²]
24
Area (projected) [m²]
20.3
Span (incl. stabiliser) [m]
11.0
Span (projected) [m]
8.6
Aspect ratio
5.1
Aspect ratio (projected)
3.7
Max. chord [m]
2.65
Line length at B [m]
6.64
Total line length [m]
333
Canopy weight [kg]
3.2
Certified weight range, powered [kg]
100-125
V-min [km/h]
22
V-trim [km/h]
35
V-max [km/h]
45+
Min. sink at optimal wing loading [m/s]
1.1
Certification
DGAC EN-B
Size

XL

Cells
50
Area [m²]
25.56
Area (projected) [m²]
21.65
Span (incl. stabiliser) [m]
11.59
Span (projected) [m]
9.06
Aspect ratio
5.25
Aspect ratio (projected)
3.79
Max. chord [m]
2.65
Line length at B [m]
7.10
Total line length [m]
352
Canopy weight [kg]
3.3
Certified weight range, powered [kg]
115-140
V-min [km/h]
22
V-trim [km/h]
35
V-max [km/h]
45+
Min. sink at optimal wing loading [m/s]
1.1
Certification
DGAC EN-B (EN-B*)
IV · Material

Cloth and warranty.

Top surface cloth
Skytex 27 and 33 gr/m2 "Zero Porosity" Ripstop Nylon
Rib reinforcement
FLEXON® batten system
Garantie
1 year / 100 hours — manufacturing defects only
V · Lines

Line chart.

Line layout per position for APCO Hybrid Paramotor.
PositionMaterialDiameter [mm]Strength [kg]
TopDyneema0.990
Mitte & Bremse MitteVektran0.9115
Mitte a, b, cVektran1.0153
Untere A, B, CAramide1.5280
Untere StAramide1.0130
Bremse oben, St obenVectran0.9115
Bremse untenDyneema2.0230
VI · Construction

About this model.

The concept targets pilots who want to fly powered AND free with a single wing — from hike-and-fly to relaxed paramotoring.

Certification: EN-B in the free-flight configuration (unsheathed lines, risers without trimmers); all but two manoeuvres were rated EN-A. The paramotor configuration with sheathed lines is aerodynamically unchanged but sits outside the EN certification frame; per-size certificates are linked in the downloads section.

If you mainly fly free, choose the Hybrid (free-flight version); if you mainly fly powered, choose this one — converting between both configurations is possible.

VI · Reviews

Pilots on video.

First-hand impressions straight from the air.

APCO Hybrid Paramotor — Pilot Review
VIII · Downloads

Manuals and certificates.

IX · FAQ

Frequently asked questions about the APCO Hybrid Paramotor.

Which size fits my take-off weight?

Four sizes S–XL. PPG all-up weights per the data sheet: 70–95 / 85–110 / 100–125 / 115–140 kg; free flight 55–75 up to 100–120 kg.

How is it certified?

All four sizes EN-B plus DGAC. Notably, per APCO: “with all but 2 manoeuvres rated EN-A”.

Does it replace a reflex wing?

No — APCO explicitly: not intended to replace reflex wings, which excel at high speeds and in rough air. Instead: “perfect for cruising around, making the entire flight envelope easier, calmer and more enjoyable” — with slower, easier launch and landing.

What differs from the free-flight Hybrid?

Same wing — ex works with sheathed lines and motor risers with trimmers.

What warranty applies?

Hybrid models: 1 year / 100 hours, manufacturing defects only.
